How to create a spotlight highlight effect in React

You need to draw a user's attention to a specific element on the page. Maybe it's a new feature they haven't tried, a form field they skipped, or the next step in an onboarding flow. The standard approach is a spotlight overlay: dim everything except the target element, then show a tooltip explaining what to do.

Most React tutorials teach this with mix-blend-mode: hard-light. That technique breaks in dark mode and with brand-colored backdrops, which is why React Joyride's GitHub has dozens of open issues about broken spotlights. As of April 2026, React Joyride (~400K weekly npm downloads) and Shepherd.js (~30K weekly downloads) aren't compatible with React 19 either, so developers are building custom solutions right now.

This tutorial builds an accessible spotlight overlay from scratch using CSS clip-path, React portals, and proper ARIA attributes. The result works in dark mode, handles dynamic layouts, and meets WCAG 2.1 AA requirements. About 200 lines of TypeScript total.

npm install @tourkit/core @tourkit/react

If you want the finished version, Tour Kit's @tourkit/react package includes a spotlight component with all the patterns covered here. But understanding the mechanics makes you a better consumer of any library.

What you'll build

A reusable spotlight overlay component that dims the page and cuts a rounded window around any target element. It tracks position on scroll and resize, renders through a React portal to avoid z-index conflicts, and traps keyboard focus. Here's the final API:

// src/components/SpotlightDemo.tsx
<SpotlightOverlay targetRef={buttonRef} onDismiss={() => setActive(false)}>
  <p>Click this button to create your first project.</p>
</SpotlightOverlay>

Prerequisites

• React 18.2+ or React 19 (both work)
• TypeScript 5.0+
• A running React project (Vite, Next.js, or Create React App)
• Basic familiarity with refs and portals

Step 1: measure the target element

Every spotlight starts with knowing where the target element is. getBoundingClientRect() gives you the element's position relative to the viewport, but you also need to track changes when the user scrolls or the layout shifts.

// src/hooks/useElementRect.ts
import { useState, useEffect, useCallback, type RefObject } from 'react';

interface ElementRect {
  top: number;
  left: number;
  width: number;
  height: number;
}

export function useElementRect(ref: RefObject<HTMLElement | null>): ElementRect | null {
  const [rect, setRect] = useState<ElementRect | null>(null);

  const update = useCallback(() => {
    if (!ref.current) return;
    const r = ref.current.getBoundingClientRect();
    setRect({ top: r.top, left: r.left, width: r.width, height: r.height });
  }, [ref]);

  useEffect(() => {
    if (!ref.current) return;

    update();

    const observer = new ResizeObserver(update);
    observer.observe(ref.current);

    window.addEventListener('scroll', update, { passive: true });
    window.addEventListener('resize', update, { passive: true });

    return () => {
      observer.disconnect();
      window.removeEventListener('scroll', update);
      window.removeEventListener('resize', update);
    };
  }, [ref, update]);

  return rect;
}

ResizeObserver catches layout changes that scroll and resize events miss. If the target element's container expands because of dynamic content, the spotlight position stays accurate. Most spotlight tutorials skip ResizeObserver entirely and end up with spotlights that drift off-target when the page layout changes.

Step 2: render the overlay through a portal

Rendering the spotlight overlay directly in your component tree is a trap. If any parent element has overflow: hidden, transform, or will-change, it creates a new stacking context, and your overlay gets clipped or buried. React portals solve this by rendering into document.body directly.

// src/components/SpotlightOverlay.tsx
import { useRef, useEffect, type ReactNode, type RefObject } from 'react';
import { createPortal } from 'react-dom';
import { useElementRect } from '../hooks/useElementRect';

interface SpotlightOverlayProps {
  targetRef: RefObject<HTMLElement | null>;
  onDismiss: () => void;
  padding?: number;
  borderRadius?: number;
  children: ReactNode;
}

export function SpotlightOverlay({
  targetRef,
  onDismiss,
  padding = 8,
  borderRadius = 8,
  children,
}: SpotlightOverlayProps) {
  const rect = useElementRect(targetRef);
  const dialogRef = useRef<HTMLDivElement>(null);

  if (!rect) return null;

  const top = rect.top - padding;
  const left = rect.left - padding;
  const width = rect.width + padding * 2;
  const height = rect.height + padding * 2;

  return createPortal(
    <div
      role="dialog"
      aria-modal="true"
      aria-label="Feature spotlight"
      ref={dialogRef}
      style={{ position: 'fixed', inset: 0, zIndex: 9999 }}
    >
      <div
        onClick={onDismiss}
        aria-hidden="true"
        style={{
          position: 'absolute',
          inset: 0,
          backgroundColor: 'rgba(0, 0, 0, 0.6)',
          clipPath: `polygon(
            0% 0%, 0% 100%,
            ${left}px 100%, ${left}px ${top}px,
            ${left + width}px ${top}px, ${left + width}px ${top + height}px,
            ${left}px ${top + height}px, ${left}px 100%,
            100% 100%, 100% 0%
          )`,
        }}
      />
      <div
        style={{
          position: 'absolute',
          top: top + height + 12,
          left: left,
          maxWidth: 320,
          background: 'white',
          borderRadius: 8,
          padding: 16,
          boxShadow: '0 4px 12px rgba(0,0,0,0.15)',
        }}
      >
        {children}
        <button onClick={onDismiss} style={{ marginTop: 8 }}>
          Got it
        </button>
      </div>
    </div>,
    document.body
  );
}

The clip-path: polygon(...) approach deserves a closer look. Instead of using mix-blend-mode: hard-light (which React Joyride uses and which breaks in dark mode), we draw a polygon that covers the entire viewport with one rectangular hole cut out. The polygon traces the viewport edge, dips inward to create the cutout, then returns to the edge. GPU-accelerated, dark-mode safe, no interaction with your page's color scheme.

As Sandro Roth documented in his evaluation of tour libraries: "The spotlight effect using CSS mix-blend-mode: hard-light breaks in certain situations such as dark mode or when your backdrop color contains a subtle shade of your brand color." The clip-path approach avoids this entirely.

Step 3: add keyboard accessibility

An overlay that traps the mouse but ignores the keyboard isn't accessible. WCAG 2.1 requires that modal-like overlays trap focus (Success Criterion 2.1.2) and provide an escape mechanism. Here's what we need:

• Escape key dismisses the overlay
• Focus is trapped within the dialog
• Background content gets the inert attribute
• Screen readers announce the spotlight via aria-live

// src/hooks/useSpotlightA11y.ts
import { useEffect, type RefObject } from 'react';

export function useSpotlightA11y(
  dialogRef: RefObject<HTMLElement | null>,
  onDismiss: () => void
) {
  useEffect(() => {
    const dialog = dialogRef.current;
    if (!dialog) return;

    // Mark background content as inert
    const root = document.getElementById('root') || document.getElementById('__next');
    if (root) root.setAttribute('inert', '');

    // Move focus into the dialog
    const focusable = dialog.querySelectorAll<HTMLElement>(
      'button, [href], input, select, textarea, [tabindex]:not([tabindex="-1"])'
    );
    focusable[0]?.focus();

    function handleKeyDown(e: KeyboardEvent) {
      if (e.key === 'Escape') {
        onDismiss();
        return;
      }

      if (e.key !== 'Tab') return;

      const first = focusable[0];
      const last = focusable[focusable.length - 1];

      if (e.shiftKey && document.activeElement === first) {
        e.preventDefault();
        last?.focus();
      } else if (!e.shiftKey && document.activeElement === last) {
        e.preventDefault();
        first?.focus();
      }
    }

    document.addEventListener('keydown', handleKeyDown);

    return () => {
      document.removeEventListener('keydown', handleKeyDown);
      if (root) root.removeAttribute('inert');
    };
  }, [dialogRef, onDismiss]);
}

Wire it into the SpotlightOverlay component by calling useSpotlightA11y(dialogRef, onDismiss) right after the useElementRect hook. The inert attribute is the modern replacement for manually setting aria-hidden and tabindex="-1" on every background element. Supported in all major browsers since 2023.

No existing spotlight tutorial covers inert for background content. TPGI's focus management guide recommends a minimum 3:1 contrast ratio for focus indicators on highlighted elements. Our clip-path approach preserves this since it doesn't alter the target element's appearance.

Step 4: respect prefers-reduced-motion

Some users experience motion sickness or vestibular disorders. When prefers-reduced-motion is active, the spotlight should appear instantly without transition animations.

// src/hooks/useReducedMotion.ts
import { useState, useEffect } from 'react';

export function useReducedMotion(): boolean {
  const [reduced, setReduced] = useState(() => {
    if (typeof window === 'undefined') return false;
    return window.matchMedia('(prefers-reduced-motion: reduce)').matches;
  });

  useEffect(() => {
    const mq = window.matchMedia('(prefers-reduced-motion: reduce)');
    const handler = (e: MediaQueryListEvent) => setReduced(e.matches);
    mq.addEventListener('change', handler);
    return () => mq.removeEventListener('change', handler);
  }, []);

  return reduced;
}

Then in SpotlightOverlay, apply the transition conditionally:

// Inside SpotlightOverlay, add to the backdrop div's style
const reducedMotion = useReducedMotion();

// On the clip-path backdrop div:
style={{
  // ...existing styles
  transition: reducedMotion ? 'none' : 'clip-path 0.3s ease-out',
}}

This way, when a user navigates between tour steps, the spotlight cutout animates smoothly to the next target. But if they've opted out of motion, it snaps instantly. This is a WCAG 2.3.3 requirement that zero existing spotlight tutorials address.

Step 5: extract a useSpotlight hook

Now extract the core logic into a single composable hook. This is the pattern Tour Kit uses internally: separate the positioning logic from the rendering so consumers own their UI completely.

// src/hooks/useSpotlight.ts
import { useState, useCallback, type RefObject } from 'react';
import { useElementRect } from './useElementRect';
import { useReducedMotion } from './useReducedMotion';

interface SpotlightConfig {
  padding?: number;
  borderRadius?: number;
}

interface SpotlightState {
  isActive: boolean;
  rect: { top: number; left: number; width: number; height: number } | null;
  reducedMotion: boolean;
  activate: () => void;
  dismiss: () => void;
  clipPath: string | null;
}

export function useSpotlight(
  targetRef: RefObject<HTMLElement | null>,
  config: SpotlightConfig = {}
): SpotlightState {
  const { padding = 8 } = config;
  const [isActive, setIsActive] = useState(false);
  const rect = useElementRect(targetRef);
  const reducedMotion = useReducedMotion();

  const activate = useCallback(() => setIsActive(true), []);
  const dismiss = useCallback(() => setIsActive(false), []);

  let clipPath: string | null = null;
  if (rect && isActive) {
    const t = rect.top - padding;
    const l = rect.left - padding;
    const w = rect.width + padding * 2;
    const h = rect.height + padding * 2;
    clipPath = `polygon(
      0% 0%, 0% 100%,
      ${l}px 100%, ${l}px ${t}px,
      ${l + w}px ${t}px, ${l + w}px ${t + h}px,
      ${l}px ${t + h}px, ${l}px 100%,
      100% 100%, 100% 0%
    )`;
  }

  return { isActive, rect, reducedMotion, activate, dismiss, clipPath };
}

This headless approach gives you full control over rendering. No library is prescribing your tooltip design, animation library, or styling system. Framer Motion for the tooltip? Radix Popover for positioning? Tailwind for the styles? The hook doesn't care.

As React Spotlight Tour's documentation notes: "Any component under SpotlightTour can use the useSpotlight hook to add an element to the tour, which means less centralized config and less silent breaks when changing selectors."

The composable hook pattern avoids the brittle CSS-selector approach that causes maintenance headaches as your app evolves.

Why clip-path beats mix-blend-mode

Here's a concrete comparison of the two approaches. We tested both in a Vite 6 + React 19 + TypeScript 5.7 project across light mode, dark mode, and a branded theme.

The clip-path approach adds zero bytes to your bundle because it's native CSS. React Joyride ships at approximately 45KB gzipped (bundlephobia) for the full library. That's significant overhead for just a spotlight effect.

One honest tradeoff: clip-path: polygon() can't produce rounded corners on the cutout. For rounded cutouts, you need clip-path: inset(top right bottom left round radius), but inset() only supports rectangular holes. If you need complex shapes (like highlighting a circular avatar), the SVG <mask> approach is better suited.

Tour Kit handles this automatically by switching between clip-path and SVG mask based on the target element's border-radius.

Common issues and troubleshooting

"The spotlight appears in the wrong position"

This happens when the target element is inside a scrollable container that isn't the viewport. getBoundingClientRect() returns coordinates relative to the viewport, not the scroll container. Fix it by adding the container's scroll offset:

// If your target is inside a scrollable div
const containerScroll = scrollContainerRef.current?.scrollTop ?? 0;
const adjustedTop = rect.top + containerScroll;

"The spotlight flickers on scroll"

Scroll events fire at ~60fps, but React state updates batch differently. Add will-change: clip-path to the overlay element so the browser skips the layout step during repaints:

.spotlight-overlay {
  will-change: clip-path;
}

Remove will-change when the spotlight is inactive. Keeping it permanently allocated wastes GPU memory.

"Focus escapes the dialog on mobile Safari"

Mobile Safari has a known issue where inert doesn't fully block VoiceOver focus on elements outside the dialog. Add aria-hidden="true" to the root element as a fallback alongside inert:

if (root) {
  root.setAttribute('inert', '');
  root.setAttribute('aria-hidden', 'true');
}

Next steps

You now have a working spotlight overlay with proper accessibility, dark mode support, and motion sensitivity. From here you can:

• Add multi-step tour logic by managing an array of target refs and stepping through them
• Implement tooltip positioning logic (flip to above/left when the tooltip would overflow the viewport)
• Add analytics tracking for which steps users complete vs. skip
• Handle edge cases like target elements that are off-screen or hidden

Or skip the custom code entirely. Tour Kit's @tourkit/react package includes all of this (spotlight overlays, multi-step tours, tooltip positioning, analytics hooks, WCAG 2.1 AA compliance) in 12KB gzipped. The useSpotlight hook pattern in this tutorial is the same architecture Tour Kit uses internally.

npm install @tourkit/core @tourkit/react

One limitation to acknowledge: Tour Kit requires React 18+ and doesn't have a visual builder. You'll write JSX to define your tour steps, which means you need React developers on the team. For teams that want a no-code builder, tools like Chameleon or Userflow are better fits, though they come with significantly higher costs and larger bundle sizes.

Check the Tour Kit documentation for the full API reference, or try the live demo on StackBlitz.

FAQ

What is a spotlight highlight component in React?

A spotlight highlight component in React dims the page background while keeping a specific element fully visible, creating a visual focus effect. It's built using a full-screen overlay with a cutout hole positioned around the target element using CSS clip-path or SVG masks. Tour Kit provides a ready-made spotlight component that handles positioning, accessibility, and dark mode automatically.

Does CSS clip-path work in all browsers?

CSS clip-path: polygon() has been supported in Chrome, Firefox, Safari, and Edge since 2020. As of April 2026, global browser support exceeds 96% according to Can I Use. The only notable exception is IE11, which is no longer supported by React 18 or 19 anyway.

How do you make a spotlight overlay accessible?

An accessible spotlight overlay needs four things: a role="dialog" container with aria-modal="true", keyboard focus trapped within the dialog, Escape key to dismiss, and inert on background content. You should also gate animations behind prefers-reduced-motion: reduce. Most spotlight libraries skip these requirements.

What is the difference between clip-path and mix-blend-mode for spotlights?

CSS clip-path cuts a transparent hole in a dark overlay using polygon coordinates. mix-blend-mode: hard-light creates the effect through color blending instead. The clip-path approach is GPU-accelerated and works in dark mode. mix-blend-mode breaks with dark backgrounds and brand colors, which is why React Joyride has persistent spotlight rendering issues.

Can I use this spotlight pattern with Next.js App Router?

Yes. The portal-based approach works with Next.js App Router. The SpotlightOverlay component must be a Client Component (add 'use client' at the top) since it uses refs, state, and document.body. Tour Kit's React package handles the client/server boundary automatically.
